NGC 6384

Also Known as: PGC 60459, UGC 10891

Object Type: Intermediate Barred Spiral Galaxy

Constellation: Ophiuchus

Distance from Earth: 76.6 million light years

Apparent Magnitude: 13.2

Coordinates: RA 17H 32M 24.302 Sec DEC 07 deg 03 min 36.97 sec

Actual Size: 150,000 light years

Apparent Dimensions: 2.45 arcminutes x 1.11 arcminutes

--------------------------------------------------------------------------

Environmental Data

Date: June 13, 2026     Start Time: 10:43 PM    End Time: 2:39 AM    SQM: 17.0

Moon Age: 27.5 days     Moonrise: 2:42 AM     Moon Illumination: 4.6%

Temperature: 77.9 degrees F    Humidity: 54%    Dew Point: 59.9 degrees F

Location: Westport, Massachusetts 02790    Sky Condition: Clear

Comment: I started around 9:30PM however using Sequence Generator Pro I did not select 'Mechanical Angle' for rotator so I had to start over. I use Mechanical Angle since I am also capturing 'flats'.

--------------------------------------------------------------------------

Imaging Scope Data

Mount: iOptron CEM120     Camera: ZWO ASI2600 monochrome     Focuser: Optec QuickSync FT20

Telescope: Celestron 11 inch SCT Edge   Focal Length: 2800mm

Focal Reducer/Field Flattener: None     Dew Heater: Kendrick dew strip

Filter Wheel : ZWO EFW 7 position 2 inch  Filter(s): Baader Lum CMOS optimized 2 inch, Baader RED CMOS optimized 2 inch, Baader GREEN CMOS optimized 2 inch, Baader BLUE CMOS optimized 2 inch

Rotator: Pegasus Falcon 2     Power Control: Pegasus Ultimate Powerbox V2

Imaging Software

Mount: iOptron Commander     Focuser: Optec FocusLynx Commander

Imaging: Sequence Generator Pro     Platesolve: ASTAP    Rotator/Control: Pegasus Unity Platform

Imaging Status

Imaging Software: Sequence Generated     Focus HFR 5.35     Platesolve: Success on 3th attempt

--------------------------------------------------------------------------

Guide Scope Data

Telescope: Stellarvue SVX130 refractor    Camera: ZWO ASI290     Focuser: Optec DirectSync SV35

Dew Heater: Kendrick dew strip    Software: PHD2    Exposure: 1 sec sec    Binning: 1x1    Tracking Result: 0.7 t0 1.0 arcseconds RMS

--------------------------------------------------------------------------

Images Taken

Number of light frames (LUM): 30        Duration: 2 minutes        Gain: 100

Number of light frames (Red): 25        Duration: 2 minutes        Gain: 100

Number of light frames (green): 25        Duration: 2 minutes        Gain: 100

Number of light frames (Blue): 25        Duration: 2 minutes        Gain: 100

Camera Temperature: 0 degrees C        Binning: 1x1        F-Stop: 10.0

Total Integration Time: 3.5 hours

--------------------------------------------------------------------------

Number of flat frames (LUM): 25        Duration: 0.11        Gain:100

Number of flat frames (Red): 25        Duration: 0.36        Gain: 100

Number of flat frames (Green): 25        Duration: 0.25        Gain: 100

Number of flat frames (Blue): 25        Duration: 0.48        Gain: 100

Flat Field Illumination: All-Pro 'Spike-a-Flat Field standard' illuminated panel

--------------------------------------------------------------------------

Number of Dark frames: 50 (from library)       Duration: 2 minutes        Gain: 100

Number of Bias frames: 50 (from library)      Duration: 0.001 seconds        Gain: 100

--------------------------------------------------------------------------

Imaging Processing

Imaging Processing Software: PixInsight

Processes utilized: Linear - calibration/integration: For each of the LUM, RED, GREEN, and BLUE lights: Flats ImageCalibration with Master Bias, Flat ImageIntegration, Images ImageCalibration with Flat Master & Dark Master, SubFrameSelector
StarAlign all calibrated lights using best LUM image as reference, ImageIntegration of each of the LUM, RED, GREEN, BLUE sets

Linear - Background extraction, Color correction, deconvolution, noise reduction:
LUM DynamicCrop to trim, GraXpert, BlurXTerminator, NoiseXterminator
RED/GREEN/BLUE DynamicCrop to trim, GraXpert, ChannelCombine to create color image using only Red/Green/Blue, BlurXTerminator, NoiseXterminator, Image Solver script, SpectroPhotometricColorCalibration

Non-Linear: LUM: MultiscaleAdaptiveStretch
Color:MultiscaleAdaptiveStretch
ImageBlend script to combine LUM and COLOR masters, GAME script to create mask of galaxy, CurvesTransformation to increase color saturation, LocalHistogramEqualize, HDRmultiscaleTransform to increase dynamic range, DynamicCrop

--------------------------------------------------------------------------

Notes:
