IC 166
Also Known as: Tombauch 3
Object Type: Open Cluster
Constellation: Cassiopeia
Distance from Earth: 16,600 Light years
Apparent Magnitude: 11.7
Coordinates: RA 01H 52M 23S DEC 61deg 51min 09sec
Actual Size: 7.5 light year in diameter
Apparent Dimensions: 7 arc-minutes
--------------------------------------------------------------------------
Environmental Data
Date: December 4, 2022 Start Time: 10:39PM End Time: 1:00AM SQM: 16.66
Moon Age: 11.9 days Moonset: 3:11AM Moon Illumination: 90.8%
Temperature: 36 degrees F Humidity: 76% Dew Point: 29 degrees F
Location: Westport, Massachusetts 02790 Sky Condition: Clear
Comment:
--------------------------------------------------------------------------
Imaging Scope Data
Mount: iOptron CEM120 Camera: ZWO ASI2600 OSC Focuser: Optec QuickSync FT20
Telescope: Celestron 11 inch SCT Edge Focal Length: 1960mm
Focal Reducer/Field Flattener: 0.7 focal reducer Filter: None
Rotator: Pegasus Falcon Power Control: Pegasus Ultimate Powerbox V2 Dew Heater: Kendrick dew strip
Imaging Software
Mount: iOptron Commander Focuser: Optec FocusLynx Commander
Imaging: Sequence Generator Pro Platesolve: ASTAP Rotator/Control: Pegasus Unity Platform
Imaging Status
Imaging Software: Sequence Generated Focus HFR 3.15 Platesolve: Good on 3rd attempt
--------------------------------------------------------------------------
Guide Scope Data
Telescope: Stellarvue SVX130 refractor Camera: ZWO ASI290 Focuser: Optec DirectSync SV35
Dew Heater: Kendrick dew strip Software: PHD2 Exposure: 2 sec Binning: 1x1 Tracking Result: .45 arc-seconds RMS
--------------------------------------------------------------------------
Images Taken
Number of light frames: 120 Duration: 1 minute Gain: 100
Camera Temperature: -10 degrees C Binning: 1x1 F-Stop: 7.0
Total Integration Time: 2 hours
--------------------------------------------------------------------------
Number of flat frames: 50 Duration: 0.15 seconds Gain: 100
Camera Temperature: -10 degrees C Binning: 1x1 F-Stop: 7.0
Flat Field Illumination: All-Pro 'Spike-a-Flat Field standard' illuminated panel
--------------------------------------------------------------------------
Number of Dark frames: 50 (from library) Duration: 1 minute Gain: 100
Camera Temperature: -10 degrees C Binning: 1x1 F-Stop: 7.0
--------------------------------------------------------------------------
Number of Bias frames: 50 (from library) Duration: 0.001 seconds Gain: 100
Camera Temperature: -10 degrees C Binning: 1x1 F-Stop: 7.0
--------------------------------------------------------------------------
Imaging Processing
Imaging Processing Software: PixInsight
Processes utilized: Linear - calibration/integration: Flats ImageCalibration with Master Bias, Flat ImageIntegration, Images ImageCalibration with Flat Master & Dark Master, Debayer, SubFrameSelector, StarAlign, ImageIntegration
Linear - Background extraction, Color correction, deconvolution, noise reduction: DynamicBackgroundExtraction, SpectroPhotometricColorCalibration, BlurXTerminator, NoiseXterminator
Non-Linear: GeneralizedHyperbolicStretch script, CurvesTransformation, DynamicCrop, HistogramTransformation, CurvesTransformation to minimize red
--------------------------------------------------------------------------
Notes:
Click Below Image for Full Size:
